BrainChild C72 temperature controller

102.00€
SKU:
C72-410001000+OM94-7
Availability:
Normally this product will be shipped in 2-3 weeks.
Shipping:
Calculated at Checkout
Application: designed for process and temperature control
Display:  4 Digit LCD multicolour display, number of displays: x 3, 0.58” (15 mm) / 0.32” (8.3 mm)
Remote Set Point:  Available
Input:  TC, RTC, mA, V
Sampling Rate:  200 msec
CT Input:  range: 0 ÷  50A VAC (accuracy: ± 5%)
CT Output:  0 ÷ 5 VDC
Output  REL: 240VAC/2A
Accuracy:  ±0.05%
Supply Voltage:  90 ÷ 250 VAC, 47÷63 Hz
Interface:  RS 485 (protocol ModBus RTU Slave Mode), Micro USB
Programming:  Push buttons or PC communication function (parameter configuration and Firmware upgrade)
Ambient Temperature:  -10 ÷ 50ºC
Protection Class:

IP50 (front)

Dimensions (W X H X D):

72 x 72 x 59 mm / cut out: 68 x 68 mm (depth 50mm)

Weight:

190gr

Item has 12 month warranty counting from the date when item was invoiced
