Product Description
| Application: | designed for process and temperature control |
| Display: | 4 Digit LCD multicolour display, number of displays: x 2, 0.58” (15 mm) / 0.3” (7.8 mm) |
| Number Of Event Inputs: | 2 (logic low (-10VDC/0.8VDC) / high 2VDC/10VDC)) see data sheet |
| Number Of Programs: | N/A |
| Number Of Segments: | N/A |
| Remote Set Point: | N/A |
| Input: | 90 ÷ 250 VAC, 47 ÷ 63 Hz |
| Sampling Rate: | 200 msec |
| CT Input: | range: 0 ÷ 50A VAC (accuracy: ± 5%) |
| CT Output: | 0 ÷ 5 VDC |
| Output | Form a relay |
| Accuracy: | ±0.05% |
| Supply Voltage: | 90 ÷ 250 VAC, 47÷63 Hz ; 11 ÷ 40 VDC / 20 ÷ 28 VAC, 47÷63 Hz |
| Interface: | RS 485 (protocol ModBus RTU Slave Mode) |
| Programming: | Push buttons or PC communication function (parameter configuration and Firmware upgrade) |
| Ambient Temperature: | -10 ÷ 50ºC |
| Protection Class: |
IP50 (front) |
| Dimensions (W X H X D): |
48 x 48 x 59 mm / cut out: 45 x 45 mm (depth 50mm) |
| Weight: |
160gr |
