Product Description
| Application: | designed to use for isolation, conversion of NAMUR, contact signals to NPN or relays outputs |
| Number of channels: | 1 channel |
| Mounting: | Power rail / DIN rail (35mm) |
| Functions: | interface for NAMUR sensors and switches extended self diagnostics and detection of cable fault SIL2 certified programmed with detachable displays 45XX |
| Input: | NAMUR / mechanical contact (0 ÷ 5kHz; 0.1ms) |
| Output: | Opto |
| Supply voltage: | 19.2 ÷ 31.2VDC |
| Auxiliary NAMUR supplies: | 8 VDC / 8mA |
| Isolation voltage: | 2.6 kVAC |
| Programming: | 4501/4511 displays |
| Ambient temperature: | -20 ÷ 60ºC |
| Protection class: | IP20 |
| Dimensions (H x W x D): | 109 x 23.5 x 104 mm |
| Weight: | 170gr |
| Certificates: | ATEX for zone 2, Marine (DNV), SIL2 |
