| Output Range: | 0÷0.7bar (0÷10psig) |
| Supply Pressure Max.: | 17bar (250psig) |
| Supply Pressure Variation: | <0.01bar (0.2psig) for 1.7bar (25psig) change |
| Air Consumption: | < 170Nl/min (6 scfh) |
| Flow Capacity: | 570Nl/min (20scfm) |
| Exhaust Capacity: | 2.8 Nl/min (0.1scfm) |
| Sensitivity: | 2.5cm (1") of water |
| Temperature: | -18÷71ºC (0÷160ºF) or -52÷90ºC (-62÷194ºF) "J" option |
| Port Size: | 1/4 NPT |
| Mounting: | pipe or pannel |
| Material: | aluminum alloy, nitrile |
| Weight: | 0.38kg (0.84Ib) |
|
Dear customers, before ordering ControlAir products, please be informed: |
Item has 12 month warranty, counting from the date when the invoice was issued.
