  • 472144

    • WTW DIQ/S 284-EF/EF/24V universal transmitter

    WTW

    3,234.00€
    SKU:
    472144
    Width:
    20.00 (cm)
    Height:
    15.00 (cm)
    Depth:
    15.00 (cm)
    Shipping:
    Calculated at Checkout
    Max Sensors:
    4
    IQ Sensor Net Connections:
    2
    Display:
    graphic TFT; 320 x 240 pixel; backlit
    Outputs:
    3 x relays, Ethernet
    Supply Voltage:
    24V AC/DC
    USB Interface:
    USB-A
    Data Logger:
    525600 data sets
    Operating Temperature:
    -20 ÷ 55ºC
    Overvoltage Protection:
    Acc. to EN 61326-1 enhanced overvoltage protection for the entire system, implemented in each component
    Protection Class:
    IP67
    Dimensions (H X W X D):
    144 x 144 x 120.2 mm
    Adding to cart… category.add_cart_announcement

    Product Description

    Designed to operate up to 4 digital IQ sensors, with Ethernet fieldbuses, internet connection and remote control, 3 x relays, for 24V AC/DC power supply.

    Read data sheet

    Other Details

    Item has 12 month warranty, counting from the date when the invoice was issued.

    Product Videos

    Custom Field

    Max Sensors 4
    IQ Sensor Net Connections 2
    Display graphic TFT; 320 x 240 pixel; backlit
    Outputs 3 x relays, Ethernet
    Supply Voltage 24V AC/DC
    USB Interface USB-A
    Data Logger 525600 data sets
    Operating Temperature -20 ÷ 55ºC
    Overvoltage Protection Acc. to EN 61326-1 enhanced overvoltage protection for the entire system, implemented in each component
    Protection Class IP67
    Dimensions (H X W X D) 144 x 144 x 120.2 mm
