Product Description
| Application: | designed for displayment of present time, date, temperature and humidity |
| Display: | LED, red, 4 x 100 mm + 2 x 57 mm, with 8-steps brightness regulation |
| Input: | temperature sensor module designed to digital temperature sensor, 2-wire connection temperature and humidity sensor module designed to digital temperature and humidity sensor, 4-wire connection |
| Displaying Range (Depends On Sensor Type): | SCT-650, SCT-653: temperature range -40°C ÷ 85°C, resolution 1°C SCT-750, SCT-753: temperature range -40°C ÷ 120°C, resolution 0,1°C; humidity range 0 ÷ 100% RH, resolution 1% time: 24h format (hours, minutes, seconds) date: day of month, month, 2 last digits of year |
| Outputs: | No output |
| Supply Voltage: | 85 ÷ 260V AC/DC, 3V, Li internal clock battery |
| Communication Interface: | RS485, ModBus RTU |
| Programming: | local keyboard or free S-Config software via the RS-485 communication port |
| Ambient Temperature: | 0 ÷ 50ºC |
| Protection Class: |
IP30 |
| Material: |
wall mounted; aluminium + methyl polymethacrylate |
| Dimensions: |
578 x 208 x 102 mm |
| Weight: |
1300gr |
