Product Description
| Application: | Designed for use with liquids and gases, refrigerants (R717, HCFC, HFC and HC) in explosive areas |
| Range: | 10 ÷ 28 bar |
| Differential: | 1.5 bar |
| Max. operating pressure: | 34bar |
| Reset function: | MAX. RESET (internal) |
| Output: | 1 x SPDT |
| Contact load: | Ui: 29V, Ii:0.5A, Pi: 1W |
| Ambient temperature: | -20 ÷ 65ºC |
| Materials: | see data sheet |
| Process connection: | G3/8" + welded nipple ø6.5/10 mm |
| Cable entry: | 2 x Pg13.5 (6 ÷ 14mm) |
| Protection class: | IP54 |
| Approvals: | CE, ATEX 1406X (Ex II 2G, Exia IIC T6...T1 Gb) |
