Product Description
| Application: | designed for use to power, isolate, convert of mA signals + HART to analogue mA signals + HART |
| Number of channels: | 2 |
| Mounting: | Power rail or DIN rail |
| Function: | 24VDC power supply via power rail or connectors fast response time splitter function SIL2 detachable display 4501/4511 |
| Input: | mA |
| Output: | mA, status relay |
| Supply voltage: | 19.2 ÷ 31.2VDC |
| Accuracy: | ±0.1% of span |
| Isolation voltage: | 2.6 kVAC |
| Response time: | < 5ms |
| Ambient temperature: | -20 ÷ 60ºC |
| Programming: | 45XX or HART |
| Protection class: | IP20/50 |
| Dimensions (H x W x D): | 109 x 23.5 x 104 mm |
| Weight: | 250gr |
| Approvals: | ATEX (zone 2), UL, DNV, SIL |
