    • PR Electronics 5714C programmable indicator

    PR electronics

    263.00€
    SKU:
    5714C
    Availability:
    Normally this product will be shipped in 3 weeks excluding weekends
    Width:
    10.00 (cm)
    Height:
    10.00 (cm)
    Depth:
    10.00 (cm)
    Shipping:
    Calculated at Checkout
    Adding to cart… category.add_cart_announcement

    Product Description

    Application: designed for measuring, displayment and control
    Display: 4 digits x 13.8 mm, LED
    Supply Voltage: 21.6 ÷ 253 VAC / 19 ÷ 300 VDC
    Isolation Voltage: 2.3 kVAC
    Accuracy: ±0.1%
    Input:
    • RTD: Pt10, Pt20, Pt50, Pt100, Pt200, Pt250, Pt300, Pt400, Pt500, Pt1000 Ni50, Ni100, Ni120, Ni1000
    • TC:  E, J, K, L, N, T, U, B, R, S,W3, W5, LR
    • current: 0/4 ÷ 20 mA (programmable)
    • voltage: 0/0.2 ÷ 1 VDC, 0/2 ÷ 10 VDC
    Output:
    • 1 x 0 ÷ 20 mA/20 ÷ 0 mA
    • 2 x relės 2 A/250 VAC (programmable with "on/off" delay)
    • error indication from Namur 43: 3.5 mA/23 mA
    Transducer Supply Voltage: 25 ÷ 15 VDC / 0 ÷ 20 mA
    Ambient Temperature: -20 ÷ 60ºC
    Special Function: CJC
    Protection Class: IP 65
    Dimensions: 48 x 96 x 120 mm / pannel cut out: 44.5 x 91.5 mm
    Approvals: CE, Det Norske Veritas, GOST

    Other Details

    Item has 12 month warranty counting from the date when item was invoiced
