Product Description
| Application: | Designed for use with liquids and gases |
| Range: | 0 ÷ 3.5 bar |
| Differential: | 0.2bar |
| Max. operating pressure: | 10bar |
| Reset function: | AUTO |
| Output: | 1 x SPDT |
| Contact load: | AC1:10A/440V; AC3:6A/440V; DC3:12W/220V |
| Medium temperature: | -40 ÷ 70ºC |
| Ambient temperature: | -40 ÷ 100ºC |
| Materials: | see data sheet |
| Process connection: | G3/8" |
| Cable entry: | Pg13.5 (5 ÷ 14mm) |
| Protection class: | IP67 |
| Approvals: | CE, Marine |
