Product Description
| Application: | Designed for process temperature control in the room |
| Range: | 80 ÷ 150ºC |
| Differential: | 7 ÷ 20ºC |
| Max. temperature: | 200ºC |
| Reset function: | AUTO |
| Output: | 1 x SPDT |
| Contact load: | AC1:16A/400V; AC3:16A/400V; AC15:10/400V; DC13:12W/220V |
| Ambient temperature: | -40 ÷ 65ºC |
| Materials: | see data sheet |
| Sensor dimensions: | ø9.5 x 85mm |
| Cap tube length: | 5m |
| Cable entry: | Pg13.5 (∅6 ÷ 14 mm) |
| Protection class: | IP30 IP44 (please order top cover, code no. 060-109766 separately) IP55 (please order special enclosing code no. 060-033066 or 060-062866 separately) |
