Product Description
| Application: | Designed for process temperature control |
| Range: | -30 ÷ 15ºC |
| ∆P at T higher/lower: | 6.0 ÷ 23ºC / 1.5 ÷ 7ºC |
| Max. temperature: | 120ºC |
| Reset function: | AUTO |
| Output: | 1 x SPDT |
| Contact load: | AC1:16A/400V; AC3:16A/400V; AC15:10/400V; DC13:12W/220V |
| Ambient temperature: | -40 ÷ 65ºC |
| Materials: | see data sheet |
| Sensor dimensions: | ∅40 x 30mm (C1 type) (see data sheet) |
| Cap tube length: | integral with thermostat |
| Cable entry: | Pg13.5 (∅6 ÷ 14 mm) |
| Protection class: | IP30 IP44 (please order top cover, code no. 060-109766 separately) IP55 (please order special enclosing code no. 060-033066 or 060-062866 separately) |
