Product Description
| Application: | Designed for use with drinking water |
| Range: | 2 ÷ 6 bar |
| Differential (∆Pmin/∆Pmax): | 0.72 ÷ 1 / 1 ÷ 2 bar |
| Max. operating pressure: | 10bar |
| Reset function: | AUTO |
| Output: | 1 x TPST |
| Contact load: | AC-3:12A/220÷415V; AC-3:9A/600V; DC-13/14:2A/220V |
| Medium temperature: | -20 ÷ 70ºC |
| Ambient temperature: | -20 ÷ 70ºC |
| Materials: | see data sheet |
| Process connection: | G1/2" (female) |
| Cable entry: | 2 x Pg16 (∅6.5 ÷ 15 mm) |
| Protection class: | IP43 |
