Product Description
| Mounting: | pipe or pannel |
| Output Range: | 0 ÷ 1bar |
| Supply Pressure Max.: | 17.5 bar |
| Temperature: | -40 ÷ 71ºC |
| Flow: | 5 SCFM (150 Nl/min) at 100 psig |
| Exhaust Capacity: | 0.4 SCFM (12Nl/min) |
| Air Consumption: | 3.0 SCFH (1.5Nl/min) |
| Supply Pressure Variation: | 0.1psi per 5 psi change in supply |
| Port Size: | #10-32 UNF - 2A thread post |
| Material: | aluminum, viton... |
| Weight: | 0.51gr |
