Product Description
| Output Range: | 0.14÷8.2bar |
| Supply Pressure Max.: | 10 bar 3.4 bar (50psig) (for Type 100LR) |
| Supply Pressure Variation: | <0.005psig at 1.7bar (25psig) range |
| Air Consumption: | 3 Nl/min |
| Flow Capacity: | 420 Nl/min at 100psig (6.8bar) |
| Exhaust Capacity: | 425 Nl/min |
| Temperature: | -29÷71ºC |
| Port Size: | 3/8 BSP |
| Material: | aluminum alloy, Buna-N, other (see data sheet) |
| Weight: | 0.635kg (1.4Ib) |
|
