Product Description
| Application: | designed for voltage supply with safety barrier for the supply of equipement mounted in hazardous areas |
| Number of channels: | 2 |
| Mounting: | DIN rail (35mm) |
| Supply voltage: | 21.6 ÷ 253 VAC / 19.2 ÷ 300VDC |
| Max required power: | ≤ 4W (2 channels) |
| Isolation voltage: | 3.75 kVAC |
| Output | relay: 250VAC/2A, 24VDC/1A |
| Ambient temperature: | -20 ÷ 60ºC |
| Protection class: |
IP20 |
| Dimensions (H x W x D): |
109 x 23.5 x 130 mm |
| Weight: |
215gr |
| Approvals: |
ATEX II (1) G Exia Ga IIC |
